Description
Electric Motor: 48 V- BLDC motor with inner rotor
Rated Output: 1 KW / 2000RPM
Max. Power: 2.5 KW
Torque: Rate:5.5Nm; Max:25Nm
Max Motor Speed: 4,000 RPM
Final Drive: 1:7.1
Drive Mode: Stage 1 (10 mph), Stage 2 (20 mph), Stage 3 (30 mph)
Cooling System: Air Cooled
Powerpack: Lithium-Ion battery
Capacity/Energy: 20 AH/960 Wh
Charging Time 100%: Standard: 4 Hours , Quick Charge: 2.5 Hours
Charging Time 80%: Standard: 3.2 Hours , Quick Charge: 2 Hours
Run Time: 2 hours in ideal conditions with full charge
Charger Line Voltage: 90-264 V/50-60 Hz
Charging Input: 1.3A@230V(AC)
Charging Power: 290 W
Frame: Aluminum twin-spar with Double-Cradle
Front Suspension: 3.9” travel
Rear Suspension: 3.8” travel DNM Rebound/Preload Adjustable
Front Brake: Hydraulic
Rear Brake: Hydraulic
Front/Rear Rims: 12×1.6
Front/Rear Tires: 60/100-12
Chain: 428
Wheel Base: 970mm (38inches)
Handlebar Height: 860mm (33.8inches)
Ground Clearance: 200mm (7.8inches)
Seat Height: Adjustable 630mm (24.8inches) / 650mm (25.5inches)
Max Load: 99lb
Weight: 106lb
Warranty – Parts & Labor: 1-Year Limited Warranty against manufacturer’s defects. Covers non-wearable items. Please contact your local dealer for warranty claims.
Warranty – Battery: 2-Year
